Epoxy NTC Surface Mount Temperature Sensor Ring Lug

Product Description:

The surface mount temperature sensor consists of the insulated wire ( cable & PVC cable, XLPE insulated wire), NTC chip and epoxy resin, and ring lug M2/M4/M5/M6. The optional resistance value range is from 0.3kΩ to 2000kΩ, and the beta value range is from 2500K to 4500K. These surface mount temperature sensors are widely used for the battery pack, solar inverter, YF, welding machine, control cabinet, etc.

Features:

Comply with RoHS standard

PVC insulated lead wires series Operating temperature range: -20℃~105℃

(PTFE) insulated lead wires series Operating temperature range: -40℃~150℃

Sensing element electrically isolated from tag

Eyelets to fit M3, M4&M5 screw sizes

The range of wire lengths is 1.97 inches to 78.74 inches (50mm to 2000mm)

miniature designed

Interchangeability

Surface mount temperature measurement

Application:

EV/HEV Bus Bars

Battery Covers

Panel Enclosures

Inverters

Welding machine

Control cabinet

Power Distribution

Thermal Management

Heat Sinks

Structure and Dimensions:

Electrical Specification:
