3950K 10Kohm NTC Thermistors For Temperature Measurement

Product Description:

This item is an MF58 series glass bead temperature sensor. As one of the NTC thermistor sensors, glass coating NTC thermistor is made of glass bead and dumet wire. The high-temperature resistance is its character. Glass coating NTC thermistor is widely applied for electronics of vehicles, home appliances, industrial equipment, etc.

Features:

Glass encapsulation

High temperature resistant

Operating temperature range: -40℃~250℃

R25℃=10KΩ±1%, B25/50=3950±1%

Application:

Home appliances

Part Number Code:

For example: B8103F3435BF: MF58 series NTC thermistor, R25℃=10kΩ±1%, B25/85=3435k±1%;

Electrical Specification:

Structure and Dimensions:

Standard packing (inner packing): 500pcs/polybag

Operation Notice:

1. The current flowing through the NTC is controlled within the Pmax range to avoid the measurement error caused by the self-heating of the component.

2. Avoid excessive heat shock, The hot air blow should beat at least 30mm to the probe in case a heat-shrink protection tube needs to be attached.
