High Precision Epoxy Digital Temperature Sensor PVC Sheathed Cable DS18B20

Brief Introduction:

The DS18B20 temperature sensor is a digital sensor widely used for temperature measurement and monitoring purposes. It is known for its accuracy, versatility, and ease of use.

Here are the key features and characteristics of the DS18B20 temperature sensor:

1. Digital Interface: The DS18B20 sensor communicates using a digital interface, making it compatible with various microcontrollers and systems. It uses the 1-Wire protocol, allowing multiple sensors to be connected on a single data line.

2. High Accuracy: The DS18B20 sensor offers high precision in temperature measurement. It can provide temperature readings with a resolution of up to 12 bits, allowing for accurate monitoring and control of temperature-sensitive applications.

3. Wide Temperature Range: The sensor is capable of measuring temperatures within a wide range, typically from -55°C to +125°C (-67°F to +257°F). This versatility makes it suitable for various environments and applications.

4. Integrated Features: The DS18B20 sensor includes several integrated features that enhance its functionality. It has built-in non-volatile memory to store calibration data and device information, allowing for easy integration and configuration.

5. Power-Supply Flexibility: The sensor operates on a wide range of power supply voltages, typically from 3.0V to 5.5V. This flexibility enables its use with different microcontroller platforms and power sources.

6. Multiple Packaging Options: The DS18B20 sensor comes in various packaging options, including waterproof and non-waterproof versions. The waterproof variant is particularly useful for applications that require temperature measurement in harsh or wet environments.

7. Easy Integration: The DS18B20 sensor is widely supported by software libraries and has a straightforward integration process. It provides a unique 64-bit ROM code for each sensor, allowing easy identification and management in multi-sensor setups.

8. Low Power Consumption: The sensor is designed to operate with minimal power consumption, making it suitable for battery-powered applications or scenarios where energy efficiency is a priority.

Measurement temperature range: -55°C - +125°C (-67°F - +257°F)

Accuracy: ±1°C.

Power supply range:3.0V-5.5V/DC

Stainless steel tube size:Approx.6.0mm(Diameter)

The stainless steel tube inside be filled in the epoxy

Features:

Comply with RoHS standard

Operating temperature range: -20℃~+80℃(Due to the wire is covered by PVC)

Stainless steel tube Φ6*50mm

Application:

Freezer

Grain elevator

Storage tank

Telecommunications room

Cable trunking

HVAC systems

Cold chain logistics

Industrial systems

Thermostat controls system

Structure and Dimensions:

You may also like:

Hefei Jingpu Sensor Technology Co., Ltd. is a national high-tech enterprise integrating R&D, production, and sales of thermistors and temperature sensors which was established in 2014 and obtained IS09001 Certification in 2015, IS013485 Certification in 2018, CE Certification for medical products in 2019, and Medical Device License and Registration Certificate in 2020.

Our products include various epoxy-encapsulated and glass-encapsulated thermistors and various shell-encapsulated temperature sensors that are widely used in the medical industry (such as monitors, medical equipment, bacterial incubators, medical refrigerators, etc.), smart wearable devices, automobiles (such as water temperature, oil temperature, air conditioner, filter, intake pressure temperature, steering wheel, rearview mirror, tyre, battery pack, etc.), home appliances (such as air conditioner, refrigerator, electric water heater, induction cooker, electronic calendar, etc.), portable power bank, fire alarm, meteorology, ocean, etc.)

Our Duty: Attentively Do Every Temperature Sensor

Our Dream: To Be One of the Most Famous Sensor Manufacturer

Our Motto: To Benefit Others Is To Benefit Oneself
