Epoxy Resin Miniature Medical NTC Temperature Probe For Temperature
Monitoring
Brief Instruction:
The item is one NTC thermistor miniature medical temperature
sensor. The miniature medical temperature sensors are encapsulated
with epoxy in polyimide tubes with OD 0.3mm. It takes the enamelled
wire with OD 0.05mm as the lead wire. The miniature thermistor
sensor resistance value shall be calibrated one by one.
Features:
Miniature designed
Typical diameter: PIφ0.30mm,
Typical wire size OD0.05mm
Fast thermal response time, for example, several seconds
Operating temperature range: 0℃~100℃
Application:
Ablation temperature monitoring
Blood temperature monitoring
Incubators, patient warming, and endovascular cooling sensors
Structure and Dimensions:(Unit: mm)
Specification:
| NO. | Name | Specification | Remarks |
| 1 | Typical Diameter | PIφ0.30mm | / |
| 2 | Typical wire size | OD0.05mm | / |
| 3 | Operating temperature range | 0℃~100℃ | / |
Standard packing (inner packing): 1 pcs/polybag
Operation Notice:
1. Application: Temperature measure ；
2. The current flowing through the NTC is controlled within the
Pmax range to avoid the measurement error caused by the
self-heating of the component.
3. Avoid excessive heat shock, The hot air blow should beat at
least 30mm to the probe in case a heat-shrink protection tube needs
to be attached.
Storage Temperature -10℃～40℃,≤75%RH； Avoid a corrosive gas and
sunlit environment; After opening the package, it needs to be
sealed again.
